Cablaj cutie de viteze — Scania P 310 DB4x2MNZ
Secțiuni
Gms, bws, panou de bord [eg (eg1 eg2)], ch 2039675- sss, ch 5208720- snl, ch 3630117- sla, ch 9134334- san
Gms, bws, instrument panel [eg (eg1)], ch -2039674 sss, ch -5208719 snl, ch -3630116 sla, ch -9134333 sanGms, bws, panou de bord [eg (eg1)], ch 2039675- sss, ch 5208720- snl, ch 3630117- sla, ch 9134334- san
Gms, bws, instrument panel [ga765, 766, 767, 866, 867 +r], ch 2038270-2076314 sss, ch 5205520-5290981 snl, ch 9132977-9168150 san, ch 3627803-3815479 slaGms, bws, instrument panel [s30 s164 pto2 eg2], ch -2039674 sss, ch -5208719 snl, ch -3630116 sla, ch -9134333 san
Gms, bws [v133 pto2 eg2, gr, grs]
Gms, coo, podea [c12, c70]
Gms, coo, gear lever [c70-c428]
Gms, coo, retarder [s43 , e30], ch 2012761- sss, ch 5135800- snl, ch 9105131- san
Gms, coo [bws, s30 pto1 eg]
Gms, coo [bws, s31 pto1 ek, coo6], ch 2012761- sss, ch 5135800- snl, ch 9105131- san
Gms, frame, power take-off [ga765, 766, 767, 866, 867, +r, pto eg]
Gms, frame [ga765, 766, 767, 866, 867, +r]
Gms, gear selector, floor [ga765, 766, 767, 866, 867, +r]
Gms, instrument panel, confirmation switch [ed, gr / Grs875, 895, 905, g670, (c103-c493)]
Gms, panou de instrumente, comutator de confirmare [eg, gr / Grs875, 895, 905, (c103-c260)]
Gms, instrument panel, gear selector [ga765, 766, 767, 866, 867, +r, floor, coo7]
Gms, instrument panel, power take-off [ga765, 766, 767, 866, 867, +r, pto eg], ch -2038269 sss, ch -5205519 snl, ch -9132976 san, ch -3627802 slaGms, instrument panel, power take-off [ga765, 766, 767, 866, 867, +r, pto eg], ch 2038270-2076314 sss, ch 5205520-5290981 snl, ch 9132977-9168150 san, ch 3627803-3815478 sla
Gms, instrument panel [ga765, 766, 767, 866, 867, +r], ch -2040738 sss, ch -5211086 snl, ch -9135263 san, ch -3632105 sla
Gms, instrument panel [ga765, 766, 767, 866, 867, +r], ch 2040739-2076314 sss, ch 5211087-5290981 snl, ch 9135264-9168150 san, ch 3632106-3815478 sla
